Jibbi Telescopic Tracked Boom Lift 1890 Primo

Price

*

  • Full electric drive
  • 4.5km/h drive speed
  • Removable power pack
  • Ultrasonic Anti-collision System (UAS)



Introducing the Jibbi 1890 PRiMO: Revolutionising Boom Lift Technology

Welcome to the future of boom lifts with the ground-breaking Jibbi 1890 PRiMO. As the first full electric, self-levelling, tracked telescopic boom in Almacrawler’s line up with electric drive and a fully removable power pack, this cutting-edge innovation is set to transform your worksite experience.

Read More

Designed to overcome job site obstacles and maximise efficiency, the Jibbi 1890 PRiMO boasts an impressive 18m working height. With its exceptional drivability up to 14m and the ability to tackle 15° lateral and longitudinal inclinations, this boom lift empowers operators to reach new heights of productivity.

One of the standout features of the Jibbi 1890 PRiMO is its infinite battery autonomy, made possible by the innovative interchangeable and fully removable Power Pack. This game-changing power solution offers unparalleled flexibility, allowing the Power Pack to be easily transported for off-site recharging. Say goodbye to downtime caused by battery constraints and embrace uninterrupted workflow.

Safety is paramount when it comes to Jibbi products, and the Jibbi 1890 PRiMO is no exception. Equipped with the ATS zero maintenance track tensioning system, this boom lift offers superior stability and control, directly connected to and controlled by the main hydraulic system.

To ensure operator safety, the Jibbi 1890 PRiMO is equipped with the AES anti-entrapment system. This intelligent feature is designed to prevent serious injuries by automatically stopping the unit, while still providing ample space for the operator to safely exit.

The Jibbi 1890 PRiMO also incorporates the UAS sensors, safeguarding aerial and travel operations. These sensors vigilantly monitor the area in front and behind the tracks, the tail swing, and above and below the basket. By detecting obstacles, they prevent collisions and provide crucial pothole and drop-off protection, ensuring a secure and accident-free environment.

Experience the future of boom lifts with the Jibbi 1890 PRiMO. Embrace unmatched efficiency, limitless autonomy, and advanced safety features. Elevate your worksite productivity to new heights and make the Jibbi 1890 PRiMO your partner in success. Contact us now to learn more and revolutionise the way you work.

Read Less

  • Height (Lift / Working) (m): 17.90 m
  • Lift Capacity (kg): 250 kg
  • Power: Electric
  • purchase_options: Hire, New
  • Workplace: Both
Productivity & Performance
Full Electric Drive

With its full electric drive, the Jibbi 1890 Primo achieves an impressive ground speed of 4.5km/h, ensuring efficient and swift operations.





PRiMO battery pack removal

Infinite Battery Autonomy

Experience the exceptional autonomy of the Jibbi 1890 PRiMO, thanks to its revolutionary interchangeable and fully removable Power Pack. This ground-breaking power solution provides limitless battery life, empowering you to work without interruption. Thanks to the forklift tyne pockets, the power pack can be easily removed and transported for off-site recharging, bidding farewell to downtime caused by battery limitations. Additionally, enjoy the freedom to select between interchangeable Lead Acid or Lithium battery packs, tailoring the power source to perfectly suit your unique requirements.





PRiMO intuitive controls

User Friendly Controls

Discover the reimagined controller, designed to streamline user experience based on industry standards and rental sector needs. Equipped with a standard Anti-Entrapment bar and comfortable joysticks, it ensures enhanced safety and effortless control. Say goodbye to complexity and experience a seamless and intuitive interface that simplifies operation.





PRiMO Automatic Tensioner System (ATS)

Automatic Tensioner System (ATS)

The zero-maintenance Automatic Tensioner System (ATS) for tracks is seamlessly integrated and controlled by the main hydraulic system, eliminating the need for regular maintenance.



Large Ground Clearance

The Jibbi boasts a fixed 2.20m undercarriage, a design feature that enables a generous ground clearance of 37cm. This elevated ground clearance proves invaluable when navigating challenging terrains and job sites that demand ample clearance.





PRiMO work lights

Work Lights

The integrated front and back LED lights allow operators to use the Jibbi 1890 Primo in any conditions.

Safety
Proactive & Dynamic Levelling

The Jibbi 1890 Primo features an advanced dynamic and automatic levelling system that takes operator safety to new heights. Designed to compensate for slopes, translate movement, and ensure level positioning at elevated heights, this innovative system represents a significant advancement in safety measures.



Anti-Entrapment System (AES)

The AES anti-entrapment system is specifically engineered to prevent the risk of serious injuries caused by operator entrapment. In the event of an operator being pressed against the unit, the system promptly stops the unit. Furthermore the innovative system automatically reverses its movement for a duration of 3-5 seconds, effectively creating a safe space for the operator to quickly and safely remove themselves from any potential danger.





PRiMO Ultrasonic Anti-collision System (UTS)

Ultrasonic Anti-Collision System (UAS)

Enhancing safety during aerial and travel operations, the Ultrasonic Anti-collision System sensors play a crucial role by constantly monitoring key areas. These sensors diligently scan the surroundings, including the front and rear of the tracks, the tail swing, and the space above and below the basket. By doing so, they effectively prevent collisions with obstacles and provide valuable protection against hazards such as potholes and drop-offs. It's important to note that the UAS sensor kit is an optional feature that can be conveniently added to the Jibbi 1890 PRiMO, further enhancing its safety capabilities based on your specific requirements.

Specifications

Jibbi Telescopic Tracked Boom Lift 1890 Primo

  1890 PRiMO
Max working height 17.90 m
Max height basket floor 15.90 m
Moving height 13.80 m
Max outreach (load 140 kg) 9.92 m
Max outreach (load 230 kg) 8.32 m
Rotation angle + / – 190 °
Basket size 1.80 x 0.70 m
Basket rotation angle + / – 70 °
Max basket capacity 250 kg (2 person)
Length in stowed position 5.86 m
Width 2.20 m
Medium working width 1.90 m
Min height in stowed position 2.16 m
Longitudinal levelling + / – 15.6 °
Lateral levelling >+ / – 15.6 °
Max gradeability 25 °
Max side gradeability 25 °
Drive speed (fast) 4.50 km/h
Drive speed at height 0.60 km/h
Anti-Entrapment System Yes
Weight ELC LTH
Traffic Load (Load in basket 140kg 4.89 kN/m 4.56 kN/m 4.57 kN/m
Total weight 6,300 kg 5,870 kg 5,910 kg
Power ELC LTH
Main Power Source Lead Acid Power Pack 420A-48V Lithium Power Pack 330A-48V Lithium Power Pack 440A-48V
Re-charging time – Output current 65A
at 230V; 25A at 85V
6.5 h at 230V 5.0 h at 230V 6.5 h at 230V
N°1 battery charger 85-265V 50/60Hz
65A max – Auto setting
Yes Yes Yes
N°2 Electric Gearmotors 7.5 kW 48V each
(IP67)
Yes Yes Yes
Electric Pump 4.5kW 48V Yes Yes Yes

Standard Equipment & Options

Standard Equipment
Full electric drive
Infinite battery autonomy
Easy battery pack removal with forklift tyne pockets
Large Basket – 1.80 x 0.70 m
190˚ turntable rotation
Basket rotation +/-70˚
User friendly controls
Fast 4.50 km/h drive speed
Automatic Proactive & Dynamic levelling
Anti-Entrapment System (AES)
Automatic Tensioner System (ATS)
Large ground clearance



Optional Equipment
Non-marking tracks
Kit work lights
Ultrasonic Anti-Collision System (UAS)

Working Envelope

PRiMO working envelope
