Haulotte Vertical Mast Star 10



  • 8 metre driveable height
  • High precision driving and smoothness
  • 24V electric dive brushless AC motors
  • Non-marking tyres


The Haulotte Vertical Mast Star 10 is a very practical and versatile boom which offers outstanding manoeuvrability. The progressive electric drive AC motors and proportional controls allows for easy, convenient access.

Read More

The vertical jib adds more versatility by providing a 3-metre horizontal outreach, making them ideal for access over obstacles or hard to reach places. The Star 10 has the ability to operate on 25% gradients, suitable for climbing truck ramps. It has a maximum lift height of 10 meters, a driveable platform height of 8 metres, and a maximum lift capacity of 200kg. And thanks to the non-marking tyres, the Star 10 is a perfect solution for any indoor and outdoor application.

Maintenance is made easy with an automatic and centralised water filling system, resulting in very little battery maintenance required. The Star 10 also comes equipped with the Haulotte Activ’Screen, this onboard screen provides crucial information of the Vertical Mast and machine diagnostics.

Vertical Mast Star 10’s are highly suited for industries that require high productivity and precision, including signage, electrical, maintenance, and many more.

Read Less

  • Lift Capacity (kg): 200 kg
  • Power: Electric
  • purchase_options: Hire, New
  • Workplace: Both
Operator Comfort
Smooth Movements

Manoeuvring the Vertical Mast has been made easy with simple controls and smooth movements.

Productivity & Performance
Driveable Working Height

The Star 10 is driveable at a working height of 8 metres for increased productivity.

Vertical Jib

The Star 10 has a 3-metre horizontal outreach for extra versatility.

Deep-cycle Batteries

Accomplish a day’s work without having to worry about recharging the battery.

Battery Indicator

A battery indicator is available on the control box for peace of mind when operating.

Automatic Protection

The emergency control button can be used to stop the lift instantly, even if it is moving.

Secure Access

The non-slip step allows for safe and quick access into the Vertical Mast.

Servicing & Maintenance
Minimal Battery Maintenance

Thanks to the automatic and centralised water filling system, the battery requires almost zero maintenance.

On-board Diagnostic Tool

Thanks to the Activ’screen, you will be able to view all crucial information of the vertical mast on an LCD display.

Easy Access to Components

There is a quick-open inspection hatch allowing easy access to the hydraulic block.


Haulotte Vertical Mast Star 10

  Star 10
Working height 10 m
Platform height 8 m
Horizontal outreach 3 m
Lift capacity – inside 200 kg
Platform size 0.78 x 0.98 m
Length 2.70 m
Width 1.0 m
Height – stowed 1.99 m
Tail swing 0 cm
Wheelbase 1.2 m
Ground clearance 10 cm
Drive speed proportional 0.6 – 5 km/h
Turning radius – outside 1.88 m
Power source 24 V – 250 Ah
Weight 2677 kg
Tilt alarm 3 °
Gradeability 25 %
Max driveable platf. Height 8 m
Hydraulic system capacity 7 l
Lift capacity – outside 200 kg
