Access Equipment
Haulotte Diesel Articulating Boom Lift HA32 RTJ PRO
Price
*
- 95 seconds to full height
- Outstanding rough terrain capabilities
- Easy maintenance
- Proportional and simultaneous movements
The Haulotte HA32 RTJ PRO diesel articulated boom lift delivers unmatched versatility, simplicity of maintenance, and an overall low cost of ownership. This state-of-the-art boom lift provides both proportional and simultaneous movements in a smooth and timely manner, as well as an excellent lifting speed of 95 seconds to full height.
Its platform height of 24.4 meters and horizontal outreach of 21.60 metres provides the boom with the ability to reach even the most challenging areas. Also, the outstanding rough terrain features include 4-wheel steering, sturdy solid tyres and oscillating, allowing the operator to drive in challenging terrain without limitations.
Read More
Maintenance is made easy with a range of inbuilt features, including a self-diagnosis tool, a modular platform for quick repairs, swing out engine tray, and easy access to all components. The HA32 RTJ PRO is an excellent choice for anyone looking for a safe and reliable boom lift.
The HA32 RTJ PRO is suitable for many industries, including electrical, plumbing, construction, maintenance, and landscaping.
Read Less
- Height (Lift / Working) (m): 31.80 m
- Lift Capacity (kg): 250 kg
- Power: Diesel
- Workplace: Outside
Specifications
Haulotte Diesel Articulating Boom Lift HA32 RTJ PRO
| Haulotte HA32 RTJ PRO | |
| Working height | 31.80 m |
| Platform height | 29.80 m |
| Horizontal outreach | 21.60 m |
| Up and over clearance | 11.35 m |
| Below ground reach | 5.50 m |
| Lift capacity | 250 kg |
| Platform size | 2.44 x 0.91 m |
| Length – stowed | 11.70 m |
| Width | 2.53 m |
| Storage / transport length | 8.90 m |
| Storage / transport height | 3.75 m |
| Width – with extended axles | 3.30 m |
| Height – stowed | 2.80 m |
| Vertical jib rotation | 140 ° (+70 / -70) |
| Platform rotation | 180 ° (+90 / -90) |
| Turntable rotation | 360 ° continuous |
| Tailswing | 3.30 m |
| Wheelbase | 3.50 m |
| Ground clearance | 38 cm |
| Tilt | 5 ° |
| Drive speed | 0.5 – 5 km/h |
| Maximum wind speed rating | 60 km/h |
| Drive speed | 0.5 – 5 km/h |
| Maximum wind speed rating | 60 km/h |
| Gradeability | 40 % |
| Tyres – form-filled | 445 / 65-22.5 |
| Turning radius – outside axle extended | 5.74 m |
| Power source | Duetz, 55 kW, Turbo Perkins, 62.5 kW, Turbo |
| Weight | 20,100 kg |
| Standard Equipment |
| Haulotte Activ’Shield Bar 2.0 |
| Universal telematics plug |
| 4-wheel drive and steer |
| Front oscillating axle increasing stability on uneven ground |
| 2 extendable axles |
| Proportional controls enhancing comfort and safety |
| 4 simultaneous movements for highest productivity |
| Differential wheel lock increasing rough terrain capacity |
| Upper control box protection cover and tool tray in plastic ultra-solid material |
| Modular large platform with drop bar entry gate |
| Power to platform |
| Basket compensation +10°C |
| Enhanced swing out engine tray for ease of maintenance |
| Sound and light alarm for tilt and load |
| Driving beacon |
| Travel alarm |
| Hour meter |
| Electric pump system and emergency descent |
| 12 V battery / electrical control system |
| Engine pre-heater with light indicator |
| Low fuel level indicator (upper control box) |
| Towing hooks |
| Options & Accessories |
| Airline to platform |
| Lateral swing door gate |
| On-board hydraulic generator 3.5 kW |
| Biodegradable hydraulic oil |
| Hydraulic oil cooler |
| Hydraulic oil in tank and circuit for warm countries |
| Cap with key for diesel tank |
| Cold weather kit |
| Pipe cradle pack |
| Glazier pack |
| Automatic Overspeed Air Shutdown Valve (electric one-way valve, flame arrestor, spark arrestor) |
| 55 W platform working light |
